प्रश्न
Calculate the current flowing through two long parallel wires carrying equal currents and separated by a distance of 1.35 cm experiencing a force per unit length of 4.76 × 10-2 N/m.
उत्तर
Given:
d = 1.35 cm = 1.35 × 10-2 m, `F/L = 4.76 xx 10^-2` N/m, I1 = I2 = I, I = ?
Formula:
`F/L = (mu_0)/(2pi)(I_1I_2)/d`
∴ `F/L = (mu_0)/(2pi) I^2/d`
∴ `4.76 xx 10^-2 = (4pi xx 10^-7)/(2pi)I^2/(1.35 xx 10^-2)`
∴ I = 56.68 A
∴ I1 = I2 = 56.68 A
APPEARS IN
संबंधित प्रश्न
If same current 'I' is flowing through two parallel wires, separated by the distance 'b' in air, then force acting per unit length of wires will be `(mu_0= "permeability of free space")`____________.
Two long conductors, separated by a distance 80 cm carry current I1 and I2 in the same direction. They exert a force F on each other. Now the current in one of them is increased to two times and its direction is reversed. The distance is also increased to 1.8 m. The new value of the force between them is ____________.
Two long and straight conductors, placed parallel to each other are separated by 20 cm. carrying current of 3A and 5A respectively in opposite direction. The force per unit length exerted by each conductor on the other is (µ0 = 4π x 10-7 Wb/Am)
Two long parallel wires, separated by a distance R have equal current I flowing in each of them. The magnetic field of one exerts a force F on the other. The distance R is increased to 4R and the current in each wire is reduced from I to I/4. What is the force between them now?
Three long, straight and parallel wires carrying currents are arranged as shown in figure. The force experienced by 10 cm length of wire Q is ____________.
State the expression for the force per unit length between two infinitely long parallel conductors carrying current and hence define the SI unit of current.
